| Type |
PR2000 |
PRL2000 |
PRN2000 |
PR3000(C) |
PR4000(C) |
| Port size (G) |
1/8", 1/4" |
1/4", 3/8" |
1/2, 3/4" |
| Port size for pressure gauge (G) |
1/8" |
1/8" |
1/4" |
| Fluid |
Air |
| Proof pressure (kgf/cm² ) |
15 |
| Max. operating pressure (kgf/cm² ) |
9.9 |
3.2 |
9.9 |
10.2 |
| Regulating range (kgf/cm² ) |
1.5~8.5 |
0.2~2 |
0.3~7 |
0.5~8.5 |
| Ambient and media temperature ( °C ) |
-5 ~ 60 With no freezing |
| Bowl material |
Polycarbonate |
| Weight (kg) |
0.16 |
0.4 |
0.8 |
| Name / Type | Part No . |
Referance Page
|
| PR2000 | PRL2000 | PRN2000 | PR3000(C) | PR4000(C) |
| PR/PW (Blacket) |
W335 |
W423 |
W522 |
A-35 |
|
Pressure gauge
|
10 kgf/cm ²
| Round |
K40110 |
K40110 |
K40210 |
A-36 |
| Square |
GK27510 |
GK27510 |
GK27510 |
A-36 |
|
4 kgf/cm²
| Round |
K40104 |
K40104 |
K40204 |
A-36 |
|
