Type |
PF2000 |
PF3000 |
PF4000 |
Port size (G) |
1/8", 1/4" |
1/4", 3/8" |
1/2, 3/4" |
Port size for pressure gauge (G)※ |
1/8" |
1/8" |
1/4 " |
Fluid |
Air |
Proof pressure (kgf/cm² ) |
15 |
Max. operating pressure (kgf/cm² ) |
10.2 |
Regulating range (kgf/cm² ) |
0.5 ~ 8.7 |
Ambient and media temperature ( °C ) |
-5 ~ 60 With no freezing |
Nominal filtration rating ( µm) |
PF:5 /PFM:1/ (95% filtered partide size) |
Bowl capacity (cm³) |
15 |
20 |
45 |
Bowl material |
Polycarbonate |
Weight (kg) |
0.15 |
0.3 |
0.6 |
※ Only for round gauge
Name / Type | Part No . |
Referance Page
|
PFM2000 | PFM3000 | PFM4000 |
PF/PL (Blacket) |
B240 |
B423 |
B540 |
A-35 |
Auto drain | N.C (Float type) ※ |
─ |
AD53 |
AD53 |
─ |
(Dif ferential pressure type) |
AD62
|
─
|
─
|
─
|
※ Mini operating: N.C-1.5 kgf/cm² |
