| Bore size of cylinder (mm) |
φ6 |
φ10 |
φ16 |
φ20 |
φ25 |
φ32 |
| Power fluid |
Filtered air with or without lubrication |
| Min operation pressure (kgf/cm²) |
1.5 |
1 |
0.5 |
| Max operation pressure (kgf/cm²) |
7 |
| Max supply pressure (kgf/cm²) |
10.5 |
| Ambient temperature (°C) |
-10 ~ 60 |
| Available speed range (mm/s) |
30 ~ 300 |
30 ~ 500 |
30 ~ 500 |
| Port size |
M5 x 0.8 |
PT 1/8" |
| Adjustable stroke (mm) |
Magnet0 ~ -5 |
